Description
-
1-inch CMOS Sensor
-
MasterShots
-
5.4K Video
-
12km FHD
Transmission [1] [2] -
Obstacle Sensing in 4 Directions
-
ADS-B
Specs
Aircraft
- Takeoff Weight 595 g
- Dimensions
Folded:
180×97×77 mm (length×width×height)
Unfolded:
183×253×77 mm (length×width×height)
- Diagonal Length 302 mm
- Max Ascent Speed
6 m/s (S Mode)
6 m/s (N Mode)
- Max Descent Speed
6 m/s (S Mode)
6 m/s (N Mode)
- Max Service Ceiling Above Sea Level 5000 m
- Max Flight Time (no wind) 31 minutes
- Max Hovering Time (no wind) 30 minutes
- Max Flight Distance (no wind) 18.5 km
- Max Flight Speed (near sea level, no wind)
19 m/s (S Mode)
15 m/s (N Mode)
5 m/s (C Mode)
- Max Wind Speed Resistance 10.7 m/s
- Max Tilt Angle
35° (S Mode)
Front: 30°, Back: 20°, Left: 35°, Right: 35° (N Mode)
- Max Angular Velocity
250°/s (S Mode)
90°/s (N Mode)
60°/s (C Mode)
- Operating Temperature Range 0° to 40°C (32° to 104°F)
- Operating Frequency
2.4 GHz
5.8 GHz
- Transmission Power (EIRP)
2.4 GHz:
FCC: ≤30 dBm
CE: ≤20 dBm
SRRC: ≤20 dBm
MIC: ≤20 dBm
5.8 GHz:
FCC: ≤30 dBm
CE: ≤14 dBm
SRRC: ≤29 dBm
- Hovering Accuracy Range
Vertical:
± 0.1 m (with vision positioning)
± 0.5 m (with GNSS positioning)
Horizontal:
± 0.1 m (with vision positioning)
± 1.5 m (with GNSS positioning)
- Propellers Quick release, low noise, folding
- Aircraft Arms Foldable
- GNSS GPS+GLONASS+GALILEO
- Compass Single Compass
- IMU Single IMU
- Internal Storage 8 GB
Intelligent Flight Battery
- Capacity[1] 3750 mAh / 3500 mAh
- Voltage 11.04 V / 11.55 V
- Max Charging Voltage 12.6 V / 13.2 V
- Battery Type LiPo 3S
- Energy 41.4 Wh / 40.42 Wh
- Weight 198 g
- Charging Temperature Range 5° to 40°C (41° to 104°F)
- Max Charging Power 38 W
- Built-in Battery N/A
Camera
- Sensor
1″ CMOS
Effective Pixels: 20 MP; 2.4μm Pixel Size
- Lens
FOV: 88°
35 mm Format Equivalent: 22 mm
Aperture: f/2.8
Shooting Range: 0.6 m to ∞
- ISO Range
Video:
100-3200 (Auto)
100-6400 (Manual)
10-Bit Dlog-M Video:
100-800 (Auto)
100-1600 (Manual)
Photo:
100-3200 (Auto)
100-12800 (Manual)
- Still Image Size
20 MP
5472×3648 (3:2)
5472×3078 (16:9)
- Still Photography Modes
Single shot: 20 MP
Burst shooting: 20 MP (continuous burst)
Auto Exposure Bracketing (AEB): 20 MP, 3/5 bracketed frames at 0.7 EV bias
Timed: 20 MP, 2/3/5/7/10/15/20/30/60s
SmartPhoto (including HDR and HyperLight): 20 MP
HDR Panorama[2]:
Vertical (3×1): 3328×8000 (width×height)
Wide-angle (3×3): 8000×6144 (width×height)
180° (3×7): 8192×3500 (width×height)
Sphere (3×8+1): 8192×4096 (width×height)
JPEG/DNG (RAW)
- Video Resolution
5.4K: 5472×3078 @ 24/25/30 fps
4K Ultra HD: 3840×2160 @ 24/25/30/48/50/60 fps
2.7K: 2688×1512 @ 24/25/30/48/50/60 fps
FHD: 1920×1080 @ 24/25/30/48/50/60/120 fps
MP4/MOV (H.264/MPEG-4 AVC, H.265/HEVC)
- Max Video Bitrate 150 Mbps
- Supported File System
FAT32/exFAT
Supports a microSD card with a capacity of up to 256 GB.
- Digital Zoom
Zoom recording is not available while recording 10-bit videos and 120fps videos.
4K/30fps:
4x;
2.7K/60fps:
4x;
2.7K/30fps:
6x;
1080p/60fps:
6x;
1080p/30fps:
8x
Gimbal
- Stabilization 3-axis (tilt, roll, pan)
- Mechanical Range
Tilt: -135° to 45°
Roll: -45° to 45°
Pan: -100° to 100°
- Pan Axis Not Controllable
- Controllable Range Tilt: -90° to 0°(default); -90° to 24° (extended)
- Max Controllable Speed (tilt) 100°/s
- Angular Vibration Range ±0.01°
Sensing System
- Forward
Precision Measurement Range: 0.38-23.8 m
Effective Sensing Speed: ≤15 m/s
Field of View (FOV): 72° (horizontal), 58° (vertical)
- Backward
Precision Measurement Range: 0.37-23.4 m
Effective Sensing Speed: ≤12 m/s
Field of View (FOV): 57° (horizontal), 44° (vertical)
- Downward
ToF Measurement Range: 0.1-8 m
Hovering Range: 0.5-30 m
Vision Sensor Hovering Range: 0.5-60 m
- Left/Right N/A
- Upward
Precision Measurement Range: 0.34-28.6 m
Field of View (FOV): 63° (horizontal), 78° (vertical)
- Downward Auxiliary Light Single LED
Video Transmission
- Transmission System
O3
2.4 GHz/5.8 GHz Auto-Switching (compatible with OcuSync 2.0)
4-antenna 2T4R
- Max Transmission Distance
12 km (FCC), 8 km (CE)
8 km (SRRC), 8 km (MIC)
- Live View Quality/Latency
Drone + Remote Controller: 1080p/30fps 12 Mbps 120 ms
Drone + DJI Smart Controller: 1080p/30fps 12Mbps 130 ms
- Max Transmission Bitrate
44 Mbps (download bitrate)
16 Mbps (live video bitrate)
- Operating Frequency
2.4 GHz
5.8 GHz
Remote Controller
- Multiple Controllers N/A
- DJI Smart Controller Supported
- Remote Controller Transmission System
When used with different aircraft hardware configurations, DJI RC-N1 Remote Controllers will automatically select the corresponding firmware version for updating and support the following transmission technologies enabled by the hardware performance of the linked aircraft models:
a. DJI Mini 2/ DJI Mavic Air 2: O2
b. DJI Air 2S: O3
c. DJI Mavic 3: O3+
- Battery Life 6 hours (4 hours when charging a mobile device)
- Supported Mobile Device Connectors Lightning, Micro USB, USB-C
- Max Supported Mobile Device Size 180×86×10 mm (length×width×height)
- Operating Temperature 0° to 40°C (32° to 104°F)
- Transmitter Power (EIRP)
2.4 GHz:
FCC: ≤26 dBm
CE: ≤20 dBm
SRRC: ≤20 dBm
MIC: ≤20 dBm
5.8 GHz:
FCC: ≤26 dBm
CE: ≤14 dBm
SRRC: ≤26 dBm
Charger
- Charging Input 100-240V, 50/60 Hz, 1.3 A
- Charging Output
Charging Port: 13.2 V⎓2.82 A
USB Port: 5 V⎓2 A
- Voltage 13.2 V
- Rated Power 38 W
Footnotes:
- 1. The two battery versions are basically the same in terms of battery life and propulsion performance.
- 2. To ensure the Panorama quality, the aircraft will crop the panoramic photos made out of multiple images. Therefore, the photo resolution may vary in different shooting scenarios.
