Description
Specifications
General
Year of introduction
2019
Main design elements
hardware
Total Weight [kg]
0.38
Width [m]
0.093
Height [m]
0.196
Depth [m]
0.017
Resolution: horizontal pixels
1920
Resolution: vertical pixels
1080
Display: width [m]
0.075
Display: height [m]
0.133
Touchscreen
Y
GNSS Receiver
GNSS Systems Supported
GPS L1 C/A, GLONASS, BeiDou, Galileo, QZSS
Number of Channels
72
Integrated SBAS
Y
Update Rate [Hz]
4
Time to first fix after cold start [s]
30
Multipath Mitigation
N
Compatible external GNSS receivers
Trimble Catalyst, Trimble R2, Trimble R1
Stand alone positional accuracy [m]
1.5
Compatible GNSS correction signals
DGPS, SBAS
Computer
Processor
Qualcomm Snapdragon 626
RAM [MB]
4000
Hard Disk [MB]
64000
Types of Replaceable Memory
MicroSD (up to 128 GB)
Audio: speaker
Y
Range measurement
N
Operating System
Android 10
Built-in Camera: megapixels
13
Hard Disk
Flash
Audio: microphone
Y
Connectivity
User Interfaces
3 programmable keys; standard Android touch panel keys; power; volume up/down
Wireless Data Transfer
Wi-Fi (802.11 a/b/g/n/ac)
Bluetooth
Y
Ports
USB 3.0 Type-C
WiFi
Y
More information
Main applications
GIS, Utilities, Government, Water Management, Forestry, Asset Management, and others
Distinguishable features
Sunlighyt readable display; GNSS receiver; 4G LTE support; Android 8.0; Google Mobile Services certified; ultra rugged design
Operation Characteristics
Integrated sensors
Compass
Operating temperature: min. [°C]
-20
Operating temperature: max. [°C]
55
Water and dust proof [IP]
IP67
Humidity resistance
95% RH non-condensing
Shock proof
1.2 m drop, MIL-STD-810G
Operation time per battery [hr]
15
Battery Field Replaceable
Y
Pole mount available
Y
